CE Approved Hospital Infusion Pump

Unit Conversion

d/min and ml/h unit can be converted.

FF Rate

100~1200ml/h(100ml/step)

KVO Rate

1~5.0ml/h

VTBI (Volume to be Injected)

1~9999ml

Cumulative Infusion Volume

0~9999.9ml

Injection Accuracy

d/min mode: ≤±3%(after calibration)

ml/h mode: ≤±5%(after calibration)

Air Bubble size

≤25μl

Anti-Bolus

Automatically release tubing pressure when there is occlusion

Alarms Information

Near infusion finished, infusion finished, door open, air bubble, forgotten operation, battery low, battery empty, abnormal running state, equipment failure, power fault, replace infusion set, drop sensor is pulled out, etc.

Power Source

Three options for power supply:

First: 100~240VAC, 50/60HZ;

Second: Inserted Li-battery 11.1V, capacity≥1800mAh, 4 hours backup time at the rate of 5ml/h for a fully charged battery;

Third: External DC 12V power supply

Drug Library

Up to 1000 drugs are provided

Dimensions

140mm(L)*128mm(W)*228mm(H)
