Features: 1. Reprogrammable image processing system together with automatic image optimize help you get the high definition diagnostic images
2. The generator, table control and flat panel detector are perfectly integrated through the workstation, to realize the automatic image stitching function.
3. Optional function of dual energy substraction provides accurate diagnostic images and improves the diagnosis rate.
4. Optional equipped with image stitching function for convenient clinical diagnosis
Availability: | |
---|---|
XRME210101082
XINDRAY
Feature:
Technical Parameters:
Output Power | 80kW |
Inverter Frequency | 440kHZ |
Dual- focus | 0.6mm/1.2mm |
Voltage | 380V ± 38V |
Frequency | 50Hz ± 1Hz |
Radiography | Tube Voltage: 40kV-150kV Tube Current: 10mA-1000mA Exposure time: 1ms-10000ms |
Fluoroscopy | Tube Voltage: 40kV-125kV Tube Current: 0.5mA-10mA (Continuous Fluroscopy) 5mA-20mA (Pulse Fluoroscopy) |
Feature:
Technical Parameters:
Output Power | 80kW |
Inverter Frequency | 440kHZ |
Dual- focus | 0.6mm/1.2mm |
Voltage | 380V ± 38V |
Frequency | 50Hz ± 1Hz |
Radiography | Tube Voltage: 40kV-150kV Tube Current: 10mA-1000mA Exposure time: 1ms-10000ms |
Fluoroscopy | Tube Voltage: 40kV-125kV Tube Current: 0.5mA-10mA (Continuous Fluroscopy) 5mA-20mA (Pulse Fluoroscopy) |
