XRME2022040306
XINDRAY
Specifications:
| Sample Type | Whole blood(lithium-heparinized), Plasma(lithium-heparinized), Serum |
| Sample Size | 100μl |
| Time to Results | About 10 minutes |
| Parameters | Up to 17 parameters in one test, 32 parameters configured into 9 profiles |
| Reagent Disc | Disposable, prepackaged with self-contained lyophilized reagent |
| Calibration | Automatic self-calibration by scanning QR Code on the aluminum foil pouch |
| Quality Control | Built-in Realtime Quality Control(RQC) system |
| User Interface | Full-color touch screen |
| Connection Interfaces | WLAN, USB port, Ethernet interface, compatible with HIS |
| Print Mode | Optional external thermal printer,Medical Data Management Platform, HIS |
| Reaction Temperature | 37ºC±0.1ºC |
| Data Capacity | More than 50,000 sets of patient and quality control data |
| Operation Environment | Temperature 10-30ºC, Humidity 40-85% |
| Power Requirement | AC 100V-240V, 50-60HZ |
| Dimensions | 21(L)*12.5(W)*17.5(H)cm |
| Weight | 2.3kg |
Easy to use:
1.Fully automated system-no special operating skills required
2.4.3 inch capacitive touch screen
3.0.1cc whole blood,serum or plasma
4.Barcoded prefabricated calibration information
5.LIS compatible, no need to manually enter patient information
6.Results can be printed on a hard copy via printer or transferred electronically, e.g. to a work station
7.Ability to print reports with your practice logo by installing the CNMEDITECH medical data management platform
Quick results:
From sample to complete results in 3 simple steps in approximately 13 minutes
Precise measurements:
Advanced technology ensures precise results
1.Microfluidic discs with pre-installed reagent beads ensure accurate analysis of blood samples and reagents
2.Stable measurement optics include a troboscopic xenon lamp, a wavelength selection system, and a multiple-wavelength detector
3.Integrated quality control software monitors the entire process in real time (ensuring consistent analysis of blood samples, reagents, microfluidic discs and chemistry analyzer)
