Applied for adult and child
With high-intelligent control system
With TFT display for ventilation parameters
Humidifier with temperature adjustment
Flow (optional) and pressure trigger
With air compressor (optional)
 |
Applied for adult and child
With high-intelligent control system
With TFT display for ventilation parameters
Humidifier with temperature adjustment
Flow (optional) and pressure trigger
With air compressor (optional)
XRME220204429
XINDRAY
Feature:
Applied for adult and child
With high-intelligent control system
With TFT display for ventilation parameters
Humidifier with temperature adjustment
Flow (optional) and pressure trigger
With air compressor (optional)
Specification:
| dimensions | 45*55*140cm |
| weight | 65kg |
| casters | Central brake with lock |
| Screen | 12inch |
| display | Colour lcd |
| Display graphics | Waveforms of p-t,f-t,v-t |
| loops | P-v,f-v(optional) |
| Screen control | Nec no dead spot at any angle |
| Air compressor specifications | |
| power | Ac 220v 土10%,50hz 土2% |
| Output pressure | 0.4+-0.1ma |
| noise | <=50db |
| Ventilator specifications | |
| Modes of ventilation | |
| vcv | Voime control ve |
| sigh | sigh |
| sippv | Assistance control |
| simv | Synchronized intermitittent mandatory ventilation |
| manual | manual |
| cpap | Continuous positive airway pressure |
| psv | pressure support ventilation |
| pcv | Pressure control ventilation |
| arpv | N/a |
| blpap | N/a |
| Ventilator parameter | |
| Tidal volume range | 10-2000ml |
| Pressure range | 50-80mbar |
| Rispriation rate range | 5-80mbar |
| Rispriation rate range | 1-99bpm(1-40bpm under simv) |
| I:e range | 4:1-1:8 |
| Oxygen concentration | 21%-100% |
| Ptrigger range | -20-20cmh2o |
| Apnea ti range | 0-6s |
| peep | |
| type | Integrated,electronic control |
| range | 0-30cmh2o |
| Alarm limits | |
| visual | No tidalvolume mv,paw,fio2 limition O2 air failure,ac power failure,backuo low No tidalvolume,mv,paw,fio2 limitaton |
| Pipeline supply | |
| Gas configuration | O2,air |
| Pipeline input range | 280-600kpa |
| Battery power | |
| Battery type | Lead-acid 12v,4ah |
| Run time | Typical30mins+ |
| Pre-settings functions | |
| language | english |
| calibration | automatic |
| General settings | N/a |
| application | |
| Patient therapy type | Audlt/peadiatric lnvasive |
| Assistant therapy | N/a |
| optional | |
| Air compressor | |
| Environment conditions | |
| Operating temp | 5℃-40℃ |
| Storage temp | -10℃-+40℃ |
| humidity | <=80% |
| Atmosphere pressure | 960hpa-1040hpa |
