Original Windows operation system based,Standard PC keyboard,Newly upgraded software.
XRMD21010202
XINDRAY
B-Ultrasound Diagnostic System
Products feature
Original Windows operation system based
Standard PC keyboard
Newly upgraded software
Powerful measurement & calculation function
Tissue harmonic imaging (THI)
Multi-format image storage
B, B/B, B/M, M, B+2M, 4B mode
Pseudo color
Free hard 3D optional
Technical Specification:
Scanning Mode: Convex/Linear/Micro-convex
Display Mode: B, B+B, B+2M, M, 4B
Scanning Depth: 40mm-250mm
Grey Scale: ≥256
Cine-Loop: ≥600 frames
Image Storage: ≥1000 frames
Hard Disk: ≥160G
Image Conversion: Up/down, left/right, black/white
Image Process: GAMA, image smoothing, THI, pseudo color, histogram, zoom, etc.
Local Zoom: ≥5 times both in real time and freeze
Measurement: General, gynecology, obstetrics, cardiac, urology, abdomen, vessel, etc.
Port: Video, XGA, USB2.0, DICOM3.0, RS-232
Monitor: 12.1 inch LCD
Body Marks: ≥95
Comment: Date & time, name, PID, sex, age, doctor, hospital, annotation(whole screen comment input)
Wide Application: Abdominal, OB/GYN, urology, cardiology, small parts examination, etc
Power Supply: AC 100V~240V, 50HZ/60HZ
Standard Configurations: 3.5MHZ Convex Probe
Optional Configuration:
7.5MHZ Linear Probe
5.0MHZ Micro-convex Probe
6.5MHZ Trans vaginal Probe
7.5MHZ Endorectal Probe
Video Printer
Biopsy Bracket
3D Software
B-Ultrasound Diagnostic System
Products feature
Original Windows operation system based
Standard PC keyboard
Newly upgraded software
Powerful measurement & calculation function
Tissue harmonic imaging (THI)
Multi-format image storage
B, B/B, B/M, M, B+2M, 4B mode
Pseudo color
Free hard 3D optional
Technical Specification:
Scanning Mode: Convex/Linear/Micro-convex
Display Mode: B, B+B, B+2M, M, 4B
Scanning Depth: 40mm-250mm
Grey Scale: ≥256
Cine-Loop: ≥600 frames
Image Storage: ≥1000 frames
Hard Disk: ≥160G
Image Conversion: Up/down, left/right, black/white
Image Process: GAMA, image smoothing, THI, pseudo color, histogram, zoom, etc.
Local Zoom: ≥5 times both in real time and freeze
Measurement: General, gynecology, obstetrics, cardiac, urology, abdomen, vessel, etc.
Port: Video, XGA, USB2.0, DICOM3.0, RS-232
Monitor: 12.1 inch LCD
Body Marks: ≥95
Comment: Date & time, name, PID, sex, age, doctor, hospital, annotation(whole screen comment input)
Wide Application: Abdominal, OB/GYN, urology, cardiology, small parts examination, etc
Power Supply: AC 100V~240V, 50HZ/60HZ
Standard Configurations: 3.5MHZ Convex Probe
Optional Configuration:
7.5MHZ Linear Probe
5.0MHZ Micro-convex Probe
6.5MHZ Trans vaginal Probe
7.5MHZ Endorectal Probe
Video Printer
Biopsy Bracket
3D Software
