3 Part Auto Hematology Analyzer

Parameters

21 parameters: WBC, Lymph#, Mid#, Gran#, Lymph%, Mid%, Gran%, RBC,
HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PDW, PCT,
P-LCR,P-LCC
3 histograms for WBC, RBC and PLT

Sample Volume

Prediluted mode 20μL
Whole blood mode 9 μL

Throughput

70 samples per hour

Display

10.4 inch TFT Touch Screen

Data Storage Capacity

Up to 500,000 results including numeric and graphical information

Communication

LAN Port supports HL7 protocol
Support bi-directional LIS

Interface

4 USB port (for external printer, software upgrade, barcode reader,
WIFI adapter,keyboard and mouse), LAN port (1)

Operating Environment

Temperature: 10°C~40°C
Humidity: 10%~90%
Air pressure: 70kPa~106kPa

Power Requirement

100V-240V
≤300VA
50Hz/60Hz

Dimension and Weight

Dimension: Depth(410 mm)*width(300 mm) *height(400 mm)
Weight: ≤20Kg
