XRME210305117
XINDRAY
Feature:
Brand-new shell and operation system ;
96/48 well plate;
High brightness and large size LED(10.4"), with touch screen input, resolution 1024*600 ;
Large intelligent operation interface, easy connecting to PC;
Flexible plate layout with Blanks, Standards, Samples, Reference, QC in one screen;
Comprehensive qualitative and quantitative data-evaluation functions with cut-offs, curve-fits and transformation formulas;
More than 20 different report formats;
Auto lamp adjustment and auto calibration, improve the efficiency of the system and reduce the cost;
Support keyboard and mouse with USB interfaces;
Stable memory stores up to twenty million test data, 500 test projects.
Technical Specification:
Range of working | 400nm-800nm |
Measurement System: | 8 Channel optical system |
Filters | 4 standard filters (405, 450, 492, 630nm), or totally 10 filters can be installed |
Reading Speed | Single wave: 5s, dual waves: 10s |
Measurement Range | 0.000~4.000Abs |
Photometric Accuracy | ±0.01Abs (0.001~1.500Abs) |
Stability | <0.005Abs |
Linearity | <±1% (0.001~1.500Abs) |
Display | 5.5” TFT LCD |
System | Win 7 and Win XP, LIS, HIS |
Calculation Method | Two-point, Linear regression method, Semi logarithmic method, Ratio log method, Full log method, Exponential regression (LOGA-C), Logit-Log, Point to point (Broken line method), Four parameter method, Two square curve, Three square curve and Three square spline |
Printer | Built-in thermal print |
Data Communication | RS232 |
